OM-BTT-E 11
Troubleshooting
Your Braising Pan will operate smoothly and efficiently if properly maintained. However, the following is a list of checks to make in
the event of a problem. If the actions suggested do not solve the problem, call your authorized Service Representative. For the phone
number of the nearest agency, call your area representative or the Parts and Service Department. If an item on the list is followed by
X, the work should only be performed by a qualified service representative.
SYMPTOM WHO WHAT TO CHECK
Pan will not heat, but
indicator light comes on. Authorized
Service Rep Only
a. Heating elements for short circuit. X
Pan will not heat, and indicator
light will not light. User a. That power supply is on.
b. Fuse(s).
Authorized
Service Rep Only
c. For loose or broken wires. X
d. Thermostat functioning, by listening for a click when the switch opens or closes. X
e. Contactor functioning. X
Pan continues to heat after it
reaches desired temperature. User a. Thermostat dial setting. Turn down if too high.
Authorized
Service Rep Only
b. Thermostat functioning. X
c. Thermostat calibration. X
d. Contactor, to determine if it is de-energized. X
Pan does not reach
desired temperature. User a. Thermostat dial setting. Turn up if too low.
Authorized
Service Rep Only
b. Heating elements for ground short or open (burned out) element. X
c. Thermostat functioning, by listening for a click when the switch opens or closes. X
d. Thermostat calibration. X
e. Contactor functioning. X
Rapid clicking noise
(chattering). User a. For low voltage.
Authorized
Service Rep Only
b. Contactor for dirt or corrosion on the contacts. X
Uneven cooking due to
“hot spots.” User a. That the pan body is level.
Uneven cooking due to
“cold spots.” Authorized
Service Rep Only
a. For open (burned out) heating element. X
b. That elements are fastened tightly to pan body. X
c. That the pan body is level. X
WARNING
USE OF ANY REPLACEMENT PARTS OTHER THAN THOSE SUPPLIED BY THE MANUFACTURER OR THEIR AUTHORIZED DISTRIBUTORS
CAN CAUSE INJURY TO THE OPERATOR AND DAMAGE TO THE EQUIPMENT AND WILL VOID ALL WARRANTIES. SERVICE PERFORMED
BY OTHER THAN FACTORY-AUTHORIZED PERSONNEL WILL VOID ALL WARRANTIES.
