4
Note
The maximum cable length of 10 kilometers (6.2 miles) for the AT-A15/
LX, AT-A22/LX, and AT-A24/LX modules assumes that the modules are
connected by a 9/125 micron single-mode fiber cable to an identical
module or a module with similar capabilities.
Note
The AT-A14 module does not require a crossover cable. The module
configures the 100/1000Base-T port automatically as either an MDI or
MDI-X port, depending on the type of end node.
AT-A15/LX
2
SC 50/125 or 62.5/125 micron
multimode fiber optic cable 2 - 550 m (7 - 1,804 ft)
3
9/125 micron single-mode
fiber optic cable 2 m - 10 km (7 ft - 6.2 mi)
AT-A22/SX SC 50/125 micron multimode
fiber optic cable 2 - 550 m (7 - 1,804 ft) 3
62.5/125 micron
multimode fiber optic cable 2 - 275 m (7 - 902 ft) 4
AT-A22/LX SC 50/125 or 62.5/125 micron
multimode fiber optic cable 2 - 550 m (7 - 1,804 ft)
3
9/125 micron single-mode
fiber optic cable 2 m - 10 km (7 ft - 6.2 mi)
AT-A24/SX MT-RJ 50/125 micron multimode
fiber optic cable 2 - 550 m (7 - 1,804 ft)
3
62.5/125 micron
multimode fiber optic cable 2 - 275 m (7 - 902 ft)
4
AT-A24/LX MT-RJ 50/125 or 62.5/125 micron
multimode fiber optic cable 2 - 550 m (7 - 1,804 ft) 3
9/125 micron single-mode
fiber optic cable 2 m - 10 km (7 ft - 6.2 mi)
1. Refer to the IEEE 802.3 Standards for additional cabling information.
2. Features a removal GBIC module.
3. Assumes a fiber optic cable rating of 500 MHz/Km.
4. Assumes a fiber optic cable rating of 200 MHz/Km.
Table 2 Cabling Specifications (Continued)
Model
Type of
Connector
Type of Cable 1 Maximum Cable Length
