6 AR400 Series Router
C613-04032-01 REV E
• The power cable is securely plugged in
• The power supply is operational
If the LEDs light incorrectly, refer to the AR Router Hardware Reference for
troubleshooting information.
Figure 2: Front and rear panels of an AR450S, showing the AC power inlet, power switch, console ports and
Ethernet ports, and their associated LEDs.
Figure 3: Rear panel of an AR410, showing the AC power inlet, power switch, console port, Ethernet ports, and
an optional PIC card.
POWER
SYN
Tx
Rx
AC Power Switch
AC Power Inlet Console Port 10/100 Switch Ports
PIC Bay (with optional
AT-AR023 SYN PIC)
CONSOLE RS-232
PIC BAY0
3X
ASYN0
2X 1X 4
POWER
10BASE-T/100BASE-TX SWITCH PORTS
X PC
= HUB
ETH0
ETH 0
