AT-B15 and AT-B17 Quick Install Guide
9
Technical Specifications
Table 5 lists the technical specifications for the expansion modules.
Table 5 Technical Specifications
Ports
AT-B15/SX One 1000BASE-SX with SC connector
AT-B15/LX One 1000BASE-LX with SC connector
AT-B17 Two 100BASE-FX with SC connectors
Cable Type
AT-B15/SX 50/125 or 62.5/125 micron multimode fiber
AT-B15/LX 50/125 or 62.5/125 micron multimode fiber
AT-B17
50/125 or 62.5/125 micron multimode or 9/125
micron single-mode fiber
Switching Method Store-and-forward
Filtering/Forwarding
Full line speed
Queue Buffer
AT-B15/SX 2 Mbytes
AT-B15/LX 2 Mbytes
AT-B17 128K bytes per port
Power Consumption
AT-B15/SX 2.4W maximum
AT-B15/LX
2.4W maximum
AT-B17 10.6W maximum
Temperature
Operating: 32° to 122° F (0° to 50° C)
Storage: -4° to 158° F (-20° to 70° C)
Operating Humidity 5% to 95% (non-condensing)
