Allied Telesyn International Corporation 3 613-50256-00 Rev A
G. lite
Requires a microfilter at the customer premise and an in-line splitter at the Central Office or wherever the
IP DSLAM may be located.
Upstream
(Kbps)
Downstream
(Kbps)
64 128
128 256
256 512
320 768
384 1024
448 1280
512 1536
Default Settings
These default settings may be changed by using the IP (or Mini) DSLAM Network Management System
(NMS); please see the NMS Users Guide for further instruction.
Port Mode
Once the ADSL link has been established, it will negotiate the best data rate possible for the line before
transmitting data.
VPI/VCI Detect ON
Once established, the ADSL link will also configure itself to the detected VPI/VCI (Virtual Path
Identifier/Virtual Channel Identifier) of packets being transmitted from the remote end station.
LED Indicators
PWR: Steady green indicates normal operation for the entire module.
Per Port
LNK: Pulsing green (once per second) indicates the ADSL connection is operational and the unit is
receiving data packets from the remote unit on the other side of the ADSL connection. Steady green
indicates the ADSL link exists but there is no traffic flow.
RX: Flashing amber indicates data is being received from the ADSL line.
TX: Flashing amber indicates data is being transmitted to the ADSL line.
