Step #5 - Making the ADSL connection. Plug the ADSL cable into the ADSL RJ-21 Connector on the
AT-NT117 or AT-NT118. Verify the ADSL connection via the LNK LED on the front of the unit; a blinking
LNK LED indicates that traffic is being received from the ADSL line.
Note: The distance of the copper cable between the Mini-DSLAM and the ADSL Modem will affect
the linking of the ADSL connection. If the distance is greater than a particular speed will support,
the units will not link up.
The AT-NT117 or AT-NT118 pinout information is as follows:
DSL
Voice
Port
Tip
Ring
Tip
Ring
1
26
1
39
14
2
27
2
40
15
3
28
3
41
16
4
29
4
42
17
5
30
5
43
18
6
31
6
44
19
7
32
7
45
20
8
33
8
46
21
9
34
9
47
22
10
35
10
48
23
11
36
11
49
24
12
37
12
50
25
Operational Modes
The AT-NT117 and AT-NT118 support both Full Rate and G.lite operational Modes. The tables below
outline the various possible speed settings for both modes.
Full Rate: G.DMT, T1.413 and Alcatel
All require an in-line splitter to be installed both at the customer premise and the Central Office or
wherever the IP DSLAM may be located.
Upstream
(Kbps)
Downstream
(Kbps)
64
128
128
256
256
512
320
768
384
1024
448
1280
512
1536
768
1792
1024
2048
1280
2304
1536
2560
3584
4608
5632
7680
