Installing the Switch
This equipment must be earthed.
Follow these steps to install the switch:
1.
Read the safety information
For safety information, see the AT-9800 Series Safety and Statutory
Information booklet. A copy of this booklet is supplied with each switch,
and can also be found on the Documentation and Tools CD-ROM or at
2.
Gather the tools and equipment you will need
If installing a DC version of the switch, you will need a DC power source,
DC supply cable, and ring connectors (see
).
If the switch is to be connected to a redundant power supply, you will need
a redundant power supply unit and cable (see
3.
Choose a suitable site for the switch
Either a flat surface or 19-inch rack.
4.
Unpack the switch
Verify the package contents. If any items are damaged or missing, contact
your sales representative.
5.
Install CAM (Optional)
If you purchased a Content Addressable Memory (CAM) module, install it
now by following the instructions in the CAM Quick Install Guide.
The CAM Quick Install Guide can be found on the AT-9800 Series Switch
Documentation and Tools CD-ROM, or can be downloaded from
6.
Place the switch in its operating location
If installing the switch in a rack:
•
Remove the rubber feet
•
Attach the rack-mounting brackets
•
Mount the switch in the rack
7.
Apply AC power to the switch (for AC models)
Plug the power cord into the AC power connector on the rear panel of the
switch (
). The Fault LED should flash for approximately
10 seconds as the switch runs internal tests.
If the LED continues to flash or remains lit, refer to the AT-9800 Series
Switch Hardware Reference for troubleshooting information.
