Rapier 48w Switch
10
Applying Power to the Switch
The specific power supply requirements for the Rapier 48w are clearly displayed
on the rear of the switch. If the supply is outside the accepted range for the
switch, the switch may not operate or damage to the switch may result.
Warning All versions of this equipment must be earthed.
Rapier 48w AC switch
Follow these instructions when powering the AC switch variant.
1. Plug the provided AC power cord into the power inlet.
2. Connect the power cord to the main power source.
3. Check that the PSU LED on the front panel of the switch is lit green. If the
LED does not light, refer to the Hardware Reference for troubleshooting
information.
WARNING
This unit might have more
than one power input. To
reduce the risk of electric
shock, disconnect all power
inputs before servicing unit.
FOR CENTRALIZED DC
POWER CONNECTION,
INSTALL ONLY IN A
RESTRICTED AREA. 40-60VDC
4.5A MAX
DUAL INPUTS
48wAC_rear_panel
