AT-6102 Installation and User Guide 8
Chapter 2
Installation
To install the Power over Ethernet Splitter, please follow the following steps in this exact order:
1. Select on the POE Splitter an output Voltage compatible with the device to be powered. Be
aware that Voltage DIP switch is factory set on 5V. When you change voltage by DIP
switching to different voltage, the Power over Ethernet Splitter must be in power off status.
2. Connect the Data In port on the Power over Ethernet Splitter to a PoE capable LAN Switch or
to the Data Out port of a POE Injector.
3. Choose the power cable (Internal Diameter 2.0mm or 2.5mm) and plug it into the Power Out
port on the Power over Ethernet Splitter.
4. Plug in the other end of the PoE Splitter’s power cable to the device to be powered (Access
Point, VoIP Phone, IP Camera …).
5. Connect the Data Out RJ-45 plug of the PoE Splitter to the powered device (Access Point,
VoIP Phone, IP Camera, …)
Specifications
Standard
IEEE802.3 10BASE-T
IEEE802.3u 100BASE-TX
IEEE802.3af Power over Ethernet
Power jack diameter
2 power cables with straight plug
Plug dimensions: 5.5 x 2.0mm, 5.5 x 2.5mm length 360mm each
Adjust Switch 4 segments switch for output voltage select.
Data In & Power In
Connector
Data and Power in pin usage :
Power : 4 & 5(V+), 7 & 8 (V-) ; 1,&2(V+), 3&6(V-)
Data :1 & 2, 3 & 6
Data Out Connector Data only out: 1 x RJ-45, Data pin 1,2,3,6
Power Out Connector
Power out jack: 5V, 7.5V, 9V, 12V (User Adjustable)
Maximum feeding current: 2.0A@5V
Maximum output power: 10W
Network Cables
10BASE-T: 2 or 4-pair UTP/STP Cat.3, 4,5 cable EIA/TIA-568 100-ohm
(100m)
100BASE-TX: 2 or 4-pair UTP/STP Cat.5 cable EIA/TIA-568 100-ohm
(100m)
LED System: power (green)
Power Input DC 48V
Operating conditions
Temperature Range: 0°C~ 40°C
Humidity: 90% (non-condensing)
Storage conditions
Temperature Range: 0°C~ 70°C
Humidity: 90% (non-condensing)
Dimension 80mm x 55mm x 26mm (L x W x H) (main device only)
EMI & Safety
certifications
CE, FCC, UL, GOST, C-Tick
Other Certifications /
Markings
WEEE, RoHS
