connections
CONNECTING A DVD PLAYER OR CABLE BOX/SATELLITE
RECEIVER (SET-TOP BOX) VIA HDMI
● When connecting an external device, match the colour of the connection terminal to the cable.
Each Cable Box/Satellite receiver (Set-Top Box) has a different back panel confi guration.
1.
Connect an HDMI Cable between the HDMI IN (1, 2, 3 or 4) jack on the TV and the HDMI jack on the DVD
Player or Cable Box / Satellite receiver (Set-Top Box).
➢ No additional Audio connection is needed for an HDMI to HDMI connection.
Caution
DVD Player or Cable Box /
Satellite receiver (Set-Top Box)
1
HDMI Cable (Not supplied)
TV REAR PANEL
TV SIDE PANEL
