Appendix D — Technical information
54
Options:
Transparency option
Document feeder option
Interface:
SCSI-2 interface, 25-pin and 50-pin SCSI-
connector
Transmission speed:
2 Mb/s
Environment:
- operating temperature:
10
°
C to 40
°
C (50 F to 104 F)
- relative humidity:
20% to 85%
- surrounding space:
10 cm (4 '') on each side, 15 cm (6 '') at the
rear side
Transparency option specifications
System:
Moving light source
Maximum resolution:
300 dpi horizontal x 600 dpi vertical
Scanning area:
Maximum 203 mm x 254 mm (8 '' x 10 '')
Lamp:
fluorescent
Power supply:
from the scanner
Interface:
15-pin cable with connector to scanner
Dimensions:
- length:
516 mm (20,3 '')
- width:
330 mm (13 '')
- height:
58 mm (2,3 '')
- weight:
4.7 kg (10.4 lb)
Environment:
- operating temperature:
10
°
C to 40
°
C (50 F to 104 F)
- relative humidity:
20% to 85%
- surrounding space:
10 cm (4 '') on each side, 15 cm (6 '') at the
rear side
