Alliance Laundry Systems FLW1525C User Manual

Page 23

Maintenance

802951

Reinstallation of Shipping Materials

To prevent damage while moving the washer, the
shipping materials MUST be reinstalled.

 Disconnect washer from electrical supply.
 While supporting the front access panel, remove

two screws from the bottom edge of the panel.

 Gently lower the panel to remove it from the

washer.

 Place the shock sleeves on all four shock

absorbers. Refer to Figure 24.

 Insert hooked end of shipping brace into the open

slot of the motor mount. Refer to Figure 24.

 Attach the brace with the five bolts and washers.

Refer to Figure 24.

 Reinstall front access panel.

Figure 24

Refer to Installation section, step 6 for proper
procedures whenever the washer is moved.

Cleaning Foreign Object Trap

The washer’s pump has a trap that may collect foreign
objects. The trap may need to be cleaned if water is
draining slower than usual. To clean:

 Disconnect washer from electrical supply.
 While supporting the front access panel, remove

two screws from the bottom edge of the panel.

 Gently lower the panel to remove it from the

washer.

NOTE: The pump may have some water in it. Use a
rag or a container to catch water. If the wash drum
is full of water, use a wet/dry shop vacuum to catch
the water.

 With rag or vacuum ready, unscrew the cap on

the left side of the pump and remove trap.

 Clean the debris from the trap.
 Reinstall the trap and access panel.
 Reconnect washer to electrical supply.

FLW2124N

Shock Sleeves

Motor Mount

Hooked End of Shipping Brace

Bolts and Lockwashers

FLW2124N
