Installation

802951

Risers

Risers (or air cushions) may have to be installed if the
pipes knock or pound when flow of water stops. The
risers are more efficient when installed as close as
possible to the water supply faucets (refer to
Figure 6).

Figure 6

Step 4: (Non-Gravity Drain Models Only)
Connect Drain Hose to Drain Receptacle

Remove the drain hose from its shipping position on
the rear of the washer by removing the shipping tape.

IMPORTANT: Drain receptacle must be capable of
handling a minimum of 1-3/8 inch (3.5 cm) outside
diameter drain hose.

Figure 7

W005I

Risers (Air Cushions)

Water Supply Faucets

W005I

FLW1963N

Shipping Tape
