Audiovox PRO 9544FT - Manual (Page 7)

RED
TO +12 VDC
IGN./CRANK
87A
85 86
30
CUT
(-) TO VEHICLE'S
CHASSIS GROUND
SIREN
EXISTING +12 VOLT
PARKING LIGHT WIRE
BLACK
+12 VDC BATTERY
Connect to a +12 Volt Battery Source.
(See Note on Voltage Sensing)
RED w/WHITE
WHITE
BLACK GROUND SOURCE
Connect to Vehicle's Chassis
EXISTING PARKING
LIGHT
WHITE w/BLACK
DARK BLUE
85
86
87A
87
30
SPLICE TO FUSED+12 VDC
BATTERY SOURCE FOR
POSITIVE SWITCHING
DOME LIGHT CIRCUIT
(FORD TYPE)
OR
CONNECT TO CHASSIS
GROUND FOR NEGATIVE
SWITCHING DOME LIGHT
CIRCUIT (GM TYPE)
TO FUSED +12 VDC
BATTERY SOURCE
SPLICE TO EXISTING
DOOR COURTESY
LIGHT WIRE
FROM DOOR PIN
SWITCH 87
ORANGE
TO GREEN w/WHITE TRACER WIRE TO
IGNITION
SWITCH
TO
START
SOLENOID
EXISTING LOW CURRENT SOLENOID
FEED WIRE (+12VDC, CRANKING ONLY)
5A
FUSE
RED
15A
FUSE
RED
CHANNEL 2
Negative Pulsed Output
for Optional
Trunk Release
Remote Starter
Window Roll Up
Page 7
PRO-9544FT
CONTROL
MODULE
OPTIONAL
SHOCK SENSOR
Red, Black, Green
