MEGAPOWER CPU 8200-0421-02, REV. E
OPERATOR’S GUIDE 19 of 21
Function Actions
Control Tour Press Next or Last to change direction (forward or reverse) for executing a tour
Press Hold to hold a tour
Press Run to restart a tour
Press Next or Last to manually step through the cameras of a tour that is on hold
Call Salvo -Call first monitor in group -enter Salvo # -press Salvo
Acknowledge Alarm -Call alarming monitor -press Ack
Control Auxiliary -Call camera -specify the Auxiliary number (1–4) (1) -press Auxiliary On or
Auxiliary Off to turn an auxiliary on or off
Note: Pressing Auxiliary On or Off without specifying the number activates the previously
specified Aux number.
View Satellite Sites -Call local monitor # -enter site # -press Site -call remote camera #
Disconnect/Log Off
Satellite -Press Site -call local camera
DirectSet
(SensorNet only) • -Press Hold only to display or close the DirectSet menu when not running a
tour or attached to an alarming monitor, or
• -Enter 0 -press Hold to display or close the DirectSet menu, or
• -Enter a number -press Hold to select a DirectSet menu command whether
or not the menu is displayed
Note: All SpeedDome Optima camera domes can receive DirectSet commands, but do
not display the menus.
Note:
(1) Auxiliary 4 is not supported by all dome/PTZ protocols and configurations.
Programming Functions
Note: The following functions can only be performed with the keyboard in Program (P) mode, indicated by a
“P” displayed in the lower right of the LCD. Enter P mode before starting the step sequence listed for each
function.
To enter P mode from a locked (L) state, enter your password and press Lock. If you need to obtain the
password, please contact your system administrator.
Function Action
Program Presets -Call monitor and camera -press + -move camera to position -enter
Preset # -press Preset Enter (or Shot Enter) -press – (minus)
Program Patterns -Call monitor and camera -enter Pattern # -press Pattern -press Prog
-maneuver camera -press Ack
Clear Patterns
(RS-422 only) -Call camera -enter Pattern # -press Pattern -press Clear
Program Monitor Tours -Call monitor -enter 62 -press Prog -enter camera # -press
CAMERA -enter dwell time (1-60) -press Prog -repeat steps 4–7 for all
subsequent cameras in tour (up to a maximum of 64 entries) -press Run
Arm Monitor -Call monitor -enter arming type ID # (301–315) -press F2
Disarm Monitor -Call monitor -enter 316 -press F2
Display Current
Monitor Arming Type -Call monitor -enter 300 -press F2
