MEGAPOWER CPU 8200-0421-02, REV. E
OPERATOR’S GUIDE 14 of 21
Programming Functions
Note: Functions having an asterisk (*) in the Function column require a supervisor or administrator-level Smart
Card for access to the PROGRAM MODE tab key.
Function Action
* Program Presets -Call monitor and camera -move camera into position
-press PROGRAM MODE tab key -enter Preset #
-press PROGRAM PRESET
soft key
* Program Patterns -Call monitor and camera -press PROGRAM MODE tab key
-press PROGRAM PATTERN soft key -enter a number (1-3)
-press PATTERN
soft key -maneuver camera
-press END soft key -press PROGRAM MODE tab key to exit
* Clear Patterns
(RS-422 only) -Press PROGRAM MODE tab key
-press PROGRAM PATTERN soft key
-press Pattern # -press CLEAR soft key
-press PROGRAM MODE tab key to exit
* Program Monitor
Tours (Scratchpad
Program)(see Note) -Call monitor -press PROGRAM MODE tab key
-press KEYB CONFIG soft key -press PROG S PAD
soft key
-enter camera #, and press ENTER
-enter dwell time (1-60) -press DWELL TIME soft key
-repeat steps 5–7 until all cameras are programmed (or the maximum count of 64
entries is reached)
-press OPERATOR tab key press Run soft key
Program Monitor
Tours (Operator-Level
Smart Card) (see
Note) -Call monitor -press USER SETTINGS tab key
-press PROG S PAD
soft key
-enter camera #, and press ENTER soft key
-enter dwell time (1-60) - press DWELL TIME soft key
- repeat steps 4–6 until all cameras are programmed (or the maximum count of 64
entries is reached)
- press OPERATOR tab key -press Run soft key
Note: Pressing the PROG S PAD
soft key deletes the previously programmed sequence, and the
“TR CLR” message displays momentarily in the monitor’s Status field.
