connecting an aUdio deVice Using aUX in
This section explains how to connect the unit to an audio device.
This unit is equipped with one audio analog jack for connecting an audio device.
AUX IN
1. Connect AUX IN (Audio) on the back of the unit to the earphone jack of the external device or audio device.
2. Touch the button repeatedly until the function LEDs are off.
• The AUX mode is active when no function LED is lit.
▪ Before moving or installing this product, be sure to turn off the power and disconnect the power cord.
ONLY FOR SERVICE
AUX IN DC 14V 4A USB
5V 500mA
ONLY FOR SERVICE
AUX IN DC 14V 4A USB
5V 500mA
ONLY FOR
SERVICE
AUX IN
DC 14V 4A
USB
5V 500mA
AUX IN
Earphones
jack
audio cable
external device
