Wireless network 125
About the Wakeup on LAN (WOL) feature
With the WOL feature, you can automatically turn on or wake up a PC with your camera. This feature has been available for Samsung
desktop PCs for the last 5 years (not available for all-in-one PCs).
Setting the PC to wake up from sleep mode
1
Click Start, and then open the Control Panel.
2
Configure the network connection.
• Windows 7:
Click Network and Internet
“ Network and Sharing
Center “ Change adapter settings.
• Windows Vista:
Click Network and Internet
“ Network and Sharing
Center “ Manage network connections.
• Windows XP:
Click Network and Internet Connection
“ Network
Connection.
3
Right click Local Area, and then click Properties.
4
Click Configure “ the Power manage tab “ Allow this
device to wake the computer.
5
Click
o.
6
Restart the PC.
Setting the PC to turn on
1
Turn on the PC and press F2 while the PC is booting.
• The BIOS setting menu will appear.
2
Select Advanced tab “ Power management Setup.
3
Select Resume on PME “ Enabled.
4
Press F10 to save your changes and continue booting.
5
Click Start, and then open the Control Panel.
6
Configure the network connection.
• Windows 7:
Click Network and Internet
“ Network and Sharing
Center “ Change adapter settings.
• Windows Vista:
Click Network and Internet
“ Network and Sharing
Center “ Manage network connections.
• Windows XP:
Click Network and Internet Connection
“ Network
Connection.
7
Select drivers related to network adapter.
8
Click Advanced tab and then set WOL menus.
