113247 - 3 www.amdry.com 5
MAXIMUM CAPACITY (DRY WEIGHT) 75 lb 34.02 kg
TUMBLER DIAMETER 37” 93.98 cm
TUMBLER DEPTH 36” 91.44 cm
TUMBLER VOLUME 22.4 cu ft 634.30 L
TUMBLER/DRIVE MOTOR 1 hp 0.75 kW
BLOWER/FAN MOTOR N/A N/A
DOOR OPENING (DIAMETER) 21-1/2” 54.61 cm
DOOR SILL HEIGHT N/A N/A
WATER CONNECTION N/A
DRYERS PER 20’/40’ CONTAINER 10 / 20
DRYERS PER 48’/53’ TRUCK 24 / 26
VOLTAGE AVAILABLE 208-460v 1, 3ø w 50/60 Hz
APPROX. NET WEIGHT 721 lb 327.04 kg
APPROX. SHIPPING WEIGHT 771 lb 349.72 kg
AIRFLOW 1,200 cfm 33.98 cmm
EXHAUST CONNECTION (DIAMETER) 10” 25.40 cm
COMPRESSED AIR CONNECTION 1/8” N.P.T.
COMPRESSED AIR VOLUME 0.75 cfh 0.02 cmh
OVEN SIZE
kW Btu/hr kcal/hr
20 68,200 17,200
24 81,900 20,600
30 102,400 25,800
33 112,600 28,400
36 122,800 31,000
40 136,500 34,400
VOLTAGE AVAILABLE 120-460v 1, 3ø w 50/60 Hz
APPROX. NET WEIGHT 757 lb 343.37 kg
APPROX. SHIPPING WEIGHT 807 lb 366.05 kg
AIRFLOW 1,350 cfm 38.23 cmm
STEAM CONSUMPTION 238.7 lb/hr 108.27 kg/hr
OPERATING STEAM PRESSURE 125 psi max 8.62 bar
EXHAUST CONNECTION (DIAMETER) 10” 25.40 cm
COMPRESSED AIR CONNECTION 1/8” F.N.P.T.
COMPRESSED AIR VOLUME 0.75 cfh 0.02 cmh
BOILER HP (NORMAL LOAD) 7
SUPPLY CONNECTION 1” F.N.P.T.
RETURN CONNECTION 1” F.N.P.T.
Shaded areas are stated in metric equivalents
!
Note
The manufacturer reserves the right to make changes in specifications at any time without notice or obligation.
ADH-75 Specifications ______________________________________________
Electric
Steam
