COnnECTIOnS
instaLLing tHe tOrOiDaL ferrite On tHe HDMi in/OUt caBLe
Wind both HDMI IN/OUT cables together, make one
turn around the core.
(Start winding at 5-10cm away from the plugs)
Close the lock back.
Lift up to release the lock and open the core.
instaLLing tHe ferrite cOre On tHe aUDiO caBLe
Place the audio cable on the opened core.
Close the lock back.
Lift up to release the lock and open the core.
