English - 9
QWERTY Side View
✎
NOTE
y
The remote side doesn’t work when the QWERTY side is up, and vice versa.
Inserting Batteries
1
2
y
Slide out the battery cover.
y
Push the button right.
3
4
y
Pull the battery tray out.
y
Insert 4 AAA batteries in the tray, insert the battery tray
into the QWERTY Remote and put the cover back on.
Initial Pairing
1. When the user inserts batteries into the QWERTY Remote, "NEED PAIRING PRESS SYM+TAB” will be displayed on the
screen.
2. Press
SYM
and
TAB
buttons at the same time more than 2 seconds.
✎
A TV can be paired with only one QWERTY Remote.
When turn on the TV, start the pairing process about 30 seconds later.
To perform the pairing process again
1. Press
MUTE
,
0
,
MUTE
and
0
on the remote side of new QWERTY Remote facing the TV.
2. Follow the initial pairing process in 3 minutes.
✎
If new QWERTY Remote doesn't paired with the TV in 3 minutes, perform the process again.
SMART
HUB
SEARCH
B
A
C
ESC
CAPS
SHIFT
SHIFT
SYM
SYM
.COM
@
2
1
3
5
4
6
8
0
7
9
#
!
$
@
^
%
&
(
*
)
-
_
+
~
`
<
[
=
]
;
/
/
>
,
}
{
|
‘
:
“
?
.
W
Q
E
S
A
D
Z
TAP
ENTER
X
T
R
Y
G
F
H
V
C
B
I
U
O
K
J
L
P
M
N
D
MENU
m
E
Convenient QWERTY keyboard to type characters in SMART HUB and
SOCIAL TV menu, etc.
SYM
: Enables the symbol printed on the lower right side of each button.
Displays the characters the user typed in.
When the user presses
ENTER
E, all characters
on the screen are removed.
OFN(Optical Finger
Navigation) Sensor
In full browser function,
it can be used as the
pointer. If the user
doesn’t press any button
during 30 seconds,
the sensor will be off
automatically.
To wake up the sensor,
press any button on the
QWERTY side.
