25
6. Configure the R/G/B Gamma settings. If you configure LUT, the gamma curve of sRGB
will be applied.
• If Linear Gray is selected, DeltaE (color difference) for the gray scale changes to less
than 1 after calibration.
• If Deep Black is selected, the black luminance becomes darker than Linear Gray after
calibration. The minimum brightness varies depending on the “Black Level” settings.
7. Start calibration.
• Select the connected calibrator, then click “Next.”
• Attach the calibrator to the indicated spot on the screen, then click “Next.”
NOTE
• Set the screensaver time to at least 30 minutes before starting measurement.
• The calibration process will be performed in full screen. To cancel a calibration that is in progress,
press the ESC key.
Using NCE (Natural Color Expert)
