Connecting to an Analog Amplifier
TV
The “AUDIO OUT (AUDIO L/R)” terminals cannot be used for external speakers. You must
hook them up to an amplifier.
When an audio amplifier is connected to the “AUDIO OUT (AUDIO L/R)” terminals:
Decrease the gain (volume) of the audio amplifier, and adjust the volume level with the
volume control on the TV.
How to Connect
1
Analog Amplifier
Audio cable
Power cord
BN68-00835C-00(002~035) 2/14/05 1:12 PM Page 33
