CONNECTIONS
Speaker Components
SUBWOOFER
(AH81-03848D)
REAR
L (AH81-03848G)
R (AH81-03848N)
CENTER
(AH81-03848F)
FRONT/REAR
(AH81-03465A)
CENTER
(AH81-03469A)
CRADLE STAND/
WALL MOUNT
HOLE COVER
FRONT/REAR
(AH81-03852A)
CENTER
(AH81-03853A)
FRONT
L (AH81-03848E)
R (AH81-03848M)
(L) (R)
(L) (R)
Installing the Cradle Stand
1. Insert the stand so that it fi ts into the hole
as described in the fi gure.
2. Turn the stand clockwise to lock it.
(Turning it counter-clockwise will loosen
from the hole.)
3. This is the completion of the stand
installation.
1 1
2 2
3 3
