English - 13
Network Connection - Wired
There are three main ways to connect your TV to your network using cable, depending on your network
setup. They are illustrated below:
✎ The TV does not support network speeds less than or equal to 10Mbps.
✎ Use Cat 6 (STP Type*) cable for the connection. (*Shielded Twisted Pair)
(HDD 5V 1A) (HDD 5V 1A)
(HDD 5V 1A) (HDD 5V 1A)
(HDD 5V 1A) (HDD 5V 1A)
The Modem Port on the Wall TV Rear Panel
LAN Cable (Not Supplied) Modem Cable (Not Supplied)
External Modem
(ADSL / VDSL / Cable TV)
(HDD 5V 1A) (HDD 5V 1A)
(HDD 5V 1A) (HDD 5V 1A)
(HDD 5V 1A) (HDD 5V 1A)
The LAN Port on the Wall TV Rear Panel
LAN Cable (Not Supplied)
(HDD 5V 1A) (HDD 5V 1A)
(HDD 5V 1A) (HDD 5V 1A)
(HDD 5V 1A) (HDD 5V 1A)
The Modem Port on the Wall
TV Rear Panel
LAN Cable
(Not Supplied)
Modem Cable
(Not Supplied) LAN Cable
(Not Supplied)
External Modem
(ADSL / VDSL / Cable TV)
IP Router that has a
DHCP Server
