12_
setting up
Removing the Fridge Door
1. With the door closed, remove the upper hinge cover
1
using a screwdriver.
2. Remove hinge screws
2
and the ground screw
3
by turning counter-clockwise, and take off
the upper hinge
4
. Be careful that the door does not fall on you as you are removing it.
3. Remove the door from the lower hinge
5
by lifting the door
straight up
6
.
4. Remove the lower hinge
7
from the bracket
8
by gently
lifting the lower hinge upwards.
Reattaching the Fridge door
To reattach the fridge doors, replace parts in reverse order.
1
4
2
3
Be sure to keep track of all
parts you are removing.
