REATTACHING THE REFRIGERATOR DOORS
Reattaching the Refrigerator Door
1) Insert the lower hinge (
➀) in the bracket lower
hinge (
➁).
2) Place the hole in the refrigerator door (
➂) over
the lower hinge (
➃).
3) Insert the upper hinge shaft (
➄) into the hole (➅). After leveling between the upper hinge hole and the
cabinet hole. Reattach hinge screws (
➆) and gound screw (➇) in the clockwise direction.
4) Put the front part of the upper hinge cover (
➈) on the front part of the upper hinge (➉) and reattach it
from the front part of the upper hinge cover first.
9
