Installing the Speakers
This speaker installation guide is for the PSN5542(BN96-01328A) speakers.
16
Parts
How to Assemble the Speakers (When using the Stand)
2EA
1EA
1EA
Speakers
1EA
Middle Cabinet
(Wall Mount Only)
Speaker Dust Cover
Speaker Cable
Screw 2EA!
Screw 6EA@
Screws
1
Remove the screws indicated on the rear of the PDP (6 screws on the left and right
sides).
