CoreModule 800
QuickStart Guide
35
Appendix C
Connector Part Numbers
The following tables provide the connectors, including the manufacturers and part numbers for the
used on the CoreModule 800, I/O Board, or Cable Adapter Board. These part numbers can be used
to determine the mating connectors, when making your own cables. All connectors use 0.100" (2.54
mm) pin spacing unless otherwise indicated.
Table C-1. CoreModule 800 Connector and Manufacturer’s Part Numbers
Connector
Pin Number
Mfg
Manufacturer’s PN
J1 – Video
44-pin, 2 mm
ADAM Tech
2BHR-44-VUB-0.138-HT
J3 – Ethernet
20-pin, 1.27 mm
Samtec
FTSH-110-04-LM-DH
J4 – Utility 1
40-pin, 1.27 mm
Samtec
FTSH-1-20-01-LM-DV-K
J5 – Utility 2
40-pin, 1.27 mm
Samtec
FTSH-1-20-01-LM-DV-K
J6 – IDE
44-pin, 2 mm
ADAM Tech
2PH2-44-SGB-0.138/.370-HT
J7 – Power
10-pin, 0.150"
Samtec
ASP-16939-17-M
Note: The following list provides the Manufacturer abbreviations used in this table and the web sites
where you can locate the required mating connector information.
• Adam Tech = Adam Technologies @
• Astron Tech = Astron Technology Co., Ltd. @
• Keystone Electronics @
• Tyco Electronics = TYCO Electronics Corp @
• Samtec = Samtec, Inc. @
Table C-2. I/O Interface Board Connector and Manufacturer’s Part Numbers
Connector
Pin Number
Manufacturer
Manufacturer’s PN
BT1 – Battery
2-pin, 20 mm Lithium
Coin Cell
Keystone
Electronics
1061
J4 – Utility 1a
Interface
40-pin, 1.27 mm
Samtec
FTSH-1-20-01-LM-DV-K
J5 – Utility 2a
Interface
40-pin, 1.27 mm
Samtec
FTSH-1-20-01-LM-DV-K
J6 – Miscell
J10 – SMBus
5-pin, 0.100"
Samtec
HMTSW-105-08-LM-S-300
J7 – Serial Ports
1 & 2
9-pins each in stack
Tyco
Electronics
1734279-3
J8 – USB Ports
0 & 1
4-pins each in stack
ADAM Tech
USB-A-D-RA-RC
J9 – Keyboard/
Mouse
6-pins each in stack
Astron Tech
13-2302-66S3-5T-R
J11 – Floppy Disk
Drive
34-pin, 0.100"
ADAM Tech
BHR-34-VUA-HT
J12 – Parallel Port
(LPT1)
25-pin
Tyco
Electronics
5747846-4
