ARTDio IPP 1000 Series
50
6-4.2 Configuration
Section Item Field Description Default
Channel Select channel/extension to be configured 1/1
Phone NO. Select local extension in the ‘Channel’ field drop
down box, click ‘select’.
Port Type Displays extension’s FXO or FXS designation
(Read Only)
Port State Select port state, ‘Enable’ or ‘Disable’ Enable
Information
Current State Displays extension’s state ‘Enable’ or ‘Disable’
Device Capacity Displays the maximum number of devices the T.38
protocol can support. 2
Current Quantity Displays the number of devices the T.38 protocol
is supporting. 0
T.38 Fax Relay
Support T.38 Select ‘Yes’ or ‘No’ to assign the T.38 protocol to
support the extension NO
Control Select ‘Enable’ or ‘Disable’ to assign the
extension’s call forwarding capability Disable
Forward to
(IPP Phone Number)
Enter the IPP phone number to receive calls
forwarded from the extension.
Click ‘Apply’ None
Call Forward
Offnet to
(Offnet Phone number)
Enter offnet phone number to receive calls
forwarded from the extension.
Click ‘Apply’ None
Barring Class ID Select the extension’s Barring Class ID 0
Trunk Group ID Select the extension’s Trunk Group ID N/A
