ARTDio IPP 1000 Series
10
3-3.1 INDICATOR DESCRIPTION
LED Label Indication Description
On Link Up Link/ACT
Flash Sending/Receiving data Package
On 100Mbps
10/100
Ethernet
100Mbps
Off 10Mbps
On
FXS off hook condition LOOP/ RING
OUT (FXS) Flash Sending
On FXO Receiving
Port
Information
LOOP/ RING
IN (FXO) Flash Ringing
PWR
On Power supply normal
ALARM On Self test detects fault or FXO line cut-off
On CPU normal operation CPU/ACT
Flash Computer in use
On TIME SERVER On-line
Flash TIME SERVER Connecting TIME SRVR
Off TIME SERVER Off-line
On Auto Answer Engaged
Device
A.ANSWER
Off Auto Answer Disengaged
3-3.2 PORT DESCRIPTION
Port
Label Description
FXS Connects to telephone or fax Voice
FXO Connects to line
To WAN RJ-45 Connects to internet Ethernet
To LAN RJ-45 Connects to local LAN
CDR SMDR call recording
RS-232
CONSOLE Console
