6 Audio Authority AVAtrix User Manual
Audio Authority AVAtrix User Manual 7
Getting Started
• Register your purchase at www.audioauthority.com/register to activate your warranty and for future up-
grade notification. Write the serial number (see AVAtrix rear panel) inside the back cover of this manual.
• Read these instructions.
• Unpack the AVX-562, assemble any expanders or accessories, and load batteries into the remote.
• Fabricate Cat 5 cables and use a professional network cable tester to test the cables.
• Connect associated equipment (see detailed instructions in the Installation Section).
• Connect the product to a suitable power outlet using only the power supply furnished.
• Perform desired setup operations; the AVAtrix PC Utility included on the flash card is recommended.
TIP: To access the menu, press MENU on the IR remote; or press and hold the knob, and touch the
front panel MENU key.
TIP: To perform password protected operations, enter “2-3-6” on the front panel.
HD Cat 5 Matrix
The AVX-562 is a six input, seven output high definition matrix router. It has one local output and six Cat 5
remote outputs, all offering component video with digital and analog audio. The Model AVX-562 performs
selection of up to six audio/video input sources by infrared control, RS-232 signals, or by manual selection.
These inputs may be component video with digital and/or analog audio, all delivered to the viewer with their
original vividness, brightness and clarity. Commercial venues, such as clubs and restaurants, as well as pri-
vate homes can benefit by using the AVAtrix to send selectable video and/or audio to remote locations.
Three different Cat 5 wallplate/receiver styles are available (Models 9878, 9879 and 9880). The wallplate/
receivers allow individual source selection by IR remote control; the output of each wallplate can also be
controlled from the AVX-562 head end. The AVX-562 delivers component video, digital and analog audio to
each wallplate/receiver over two Cat 5 cables. The AVAtrix is expandable up to 36 remote wallplate outputs by
adding Model 1176 Cat 5 Matrix Expanders.
Carton Contents
• Model AVX-562 High Definition Cat 5 Matrix
• 18-volt power supply
• Model 1105BK infrared remote control with batteries
• Rack ears
• User manual
• Flash memory card with operational software and setup files (installed in AVX-562 flash card port)
!
!
