SP5, SP10, SP10R, SP20, and SP20R Solar Panels

FIGURE 3-2. SP10, SP10R mounting

α

FIGURE 3-3. Solar panel orientation

SP10

Solar Panel

Tilt Angle

Lock Washer

Flat Washer

Nut

U-bolt

Tilt Angle
Adjustment
Bolt

3
