SDM-AO4A Four Channel Analog Output
FIGURE 2. Synchronous Mode
In sequential mode, the channels are set sequentially. The output signal can
take from 600 µsecs to 1 ms (worst case) to settle to 16-bit resolution with a
10V step change. The four outputs then update 1 ms apart.
SDM Transmission
Vout 1 to Vout 4
5
