SDM-AO4A Four Channel Analog Output
2: Excite-Delay (SE) (P4)
1: 1
Reps
2: 5 2500 mV Slow Range
3: 1 SE Channel
4: 1 Excite all reps w/Exchan 1
5: 2 Delay (0.01 sec units)
6: 2500 mV Excitation
7: 2 Loc [ WD_0_360 ]
8: 0.142 Mult
9: 0 Offset
; Code for CS500 measurement, AirTC and RH:
3: Volt (SE) (P1)
1: 1
Reps
2: 25 2500 mV 60 Hz Rejection Range
3: 3 SE Channel
4: 3 Loc [ Temp_C ]
5: 0.1 Mult
6: -40.0 Offset
4: Volt (SE) (P1)
1: 1
Reps
2: 25 2500 mV 60 Hz Rejection Range
3: 2 SE Channel
4: 4 Loc [ RH ]
5: 0.1 Mult
6: 0 Offset
; Output Data Every Minute
5: If time is (P92)
1: 0
Minutes (Seconds --) into a
2: 1 Interval (same units as above)
3: 10 Set Output Flag High (Flag 0)
6: Set Active Storage Area (P80)
;Set array ID to 101
1: 1 Final Storage Area 1
2: 101 Array ID
7: Real Time (P77)
; Output Year, Day, Hour/Minute
1: 1110 Year,Day,Hour/Minute (midnight = 0000)
8: Wind Vector (P69)
; Output Average WS, WD, StdDev WD
1: 1 Reps
2: 0 Samples per Sub-Interval
3: 0 S, theta(1), sigma(theta(1)) with polar sensor
4: 1 Wind Speed/East Loc [ WS_ms ]
5: 2 Wind Direction/North Loc [ WD_0_360 ]
9: Average (P71)
; Output Average Temperature
1: 1 Reps
2: 3 Loc [ Temp_C ]
