SDM-AO4 Four Channel Analog Output
6.3.2 CR10X Program Example
Although this program is for a CR10X, programming for other Edlog
dataloggers is similar.
;{CR10X}
*Table 1 Program
01: 1.0000 Execution
Interval (seconds)
; Code for 03001 wind measurements, WS_ms & WindDir:
1: Pulse (P3)
1: 1
Reps
2: 1 Pulse Channel 1
3: 21 Low Level AC, Output Hz
4: 1 Loc [ WS_ms ]
5: 0.75 Mult
6: 0.2 Offset
2: Excite-Delay (SE) (P4)
1: 1
Reps
2: 5 2500 mV Slow Range
3: 1 SE Channel
4: 1 Excite all reps w/Exchan 1
5: 2 Delay (0.01 sec units)
6: 2500 mV Excitation
7: 2 Loc [ WD_0_360 ]
8: 0.142 Mult
9: 0 Offset
; Code for CS500 measurement, AirTC and RH:
3: Volt (SE) (P1)
1: 1
Reps
2: 25 2500 mV 60 Hz Rejection Range
3: 3 SE Channel
4: 3 Loc [ Temp_C ]
5: 0.1 Mult
6: -40.0 Offset
4: Volt (SE) (P1)
1: 1
Reps
2: 25 2500 mV 60 Hz Rejection Range
3: 2 SE Channel
4: 4 Loc [ RH ]
5: 0.1 Mult
6: 0 Offset
; Output Data Every Minute
