SC100 ISOLATED RS-232 BAUD RATE CONVERTER INTERFACE

6

14:

P30

Z=F

01:

17

F

command character (ctrl Q)

02:

00

Exponent of 10

03:

10

Z Loc :

15:

P30

Z=F

01:

73

F

command character ( I )

02:

00

Exponent of 10

03:

11

Z Loc :

16:

P30

Z=F

01:

83

F

command character ( S )

02:

00

Exponent of 10

03:

12

Z Loc :

17:

P15

Port Serial I/O (Special)

01:

1

Rep

02:

01

Configuration code

03:

1

CTS/Delay

04:

1

First control port

05:

10

Output Loc

06:

3

No. of locs to send

07:

13

Termination character

08:

0

Maximum characters

09:

1

CTS/Input wait

10:

2

Loc :

11:

1

Mult

12:

0

Offset

18:

P86

Do

01:

21

Set low Flag 1

19:

P95

End

Example of how to initialize the SC100's search/find & replace structure

20:

P91

If Flag/Port

01:

13

Do if flag 3 is high

02:

30

Then Do

21:

P30

Z=F

01:

17

F

command character (ctrl Q)

02:

00

Exponent of 10

03:

10

Z Loc :

22:

P30

Z=F

01:

73

F

command character ( I )

02:

00

Exponent of 10

03:

11

Z Loc :

23:

P30

Z=F

01:

49

F

command character ( 1 )

02:

00

Exponent of 10

03:

12

Z Loc :

24:

P30

Z=F

01:

66

F

search byte 1 (B)
