SC100 ISOLATED RS-232 BAUD RATE CONVERTER INTERFACE
5
Example of how to configure the SC100 to set up baud rate, parity and error detection
03:
P91
If Flag/Port
01:
26
Do if flag 6 is low
02:
30
Then Do
04:
P30
Z=F
01:
17
F
command character (ctrl Q)
02:
00
Exponent of 10
03:
10
Z Loc :
05:
P30
Z=F
01:
73
F
command character ( I )
02:
00
Exponent of 10
03:
11
Z Loc :
06:
P30
Z=F
01:
66
F
command character ( B )
02:
00
Exponent of 10
03:
12
Z Loc :
07:
P30
Z=F
01:
18
F
byte 1 ( baud rate --> 9600)
02:
00
Exponent of 10
03:
13
Z Loc :
08:
P30
Z=F
01:
08
F
byte 2 ( no error, no parity, half duplex)
02:
00
Exponent of 10
03:
14
Z Loc :
10:
P15
Port Serial I/O (Special)
01:
1
Rep
02:
01
Configuration code
03:
1
CTS/Delay
04:
1
First control port
05:
10
Output Loc
06:
5
No. of locs to send
07:
13
Termination character
08:
0
Maximum characters
09:
20
CTS/Input wait
10:
3
Loc :
11:
1
Mult
12:
0
Offset
11:
P86
Do
01:
16
Set high Flag 6
12:
P95
End
Example of how to configure the SC100 to transparent mode
13:
P91
If Flag/Port
01:
11
Do if flag 1 is high
02:
30
Then Do
