SC100 ISOLATED RS-232 BAUD RATE CONVERTER INTERFACE
8
35:
P30
Z=F
01:
13
F
termination character ( carriage return)
02:
00
Exponent of 10
03:
24
Z Loc :
37:
P15
Port Serial I/O (Special)
01:
1
Rep
02:
01
Configuration code
03:
1
CTS/Delay
04:
1
First control port
05:
10
Output Loc
06:
15
No. of locs to send
07:
13
Termination character
08:
0
Maximum characters
09:
100
CTS/Input wait
10:
3
Loc :
11:
1
Mult
12:
0
Offset
38:
P86
Do
01:
23
Set low Flag 3
39:
P95
End
Example of how to receive buffered information
40:
P91
If Flag/Port
01:
44
Do if port 4 is high
02:
30
Then Do
41:
P15
Port Serial I/O (Special)
01:
1
Rep
02:
01
Configuration code
03:
1
CTS/Delay
04:
1
First control port
05:
9
Output Loc
06:
1
No. of locs to send
07:
13
Termination character
08:
100
Maximum characters
09:
1000
CTS/Input wait
10:
1
Loc :
11:
1
Mult
12:
0
Offset
42:
P95
End
