Campbell Scientific PVS4100/4120/4150 Portable Automatic Samplers - Manual (Page 17)

Section 1. Product Overview
1-9
1.3 Specifications
1.3.1 PVS4100 Portable Sampler Specifications
TABLE 1-4. PVS4100 Sampler Specifications
Dimensions Height: 809 mm (31.875 in)
Diameter: 428 mm (16.85 in)
Extended Base:
Height: 962 mm (37.875 in)
Diameter: 428 mm (16.85 in)
Weight
(without battery) 11.8 kg (26 lbs)
Enclosure Molded medium density linear polyethylene, 3 piece
construction, all SS fittings.
Protection Rating: IP 55, Dust protection, water jets.
Power
Requirements Sampler: DC Output: 13.6V, 10A. AC Input: 88-
264VAC, 50/60Hz, 2.5A (max 3A)
Integral Battery: 12VDC, 17AH, 15 lbs.
External Receptacle: 12 VDC.
Optional AC only model available (no battery).
Cooling System Insulated container wall. Cavity space for ice.
Operating
Temperature Standard: 10ºC to 50ºC (50ºF to 122ºF)
* Can be modified to operate down to 0ºC (32ºF) upon
request.
Storage
Temperature -30ºC to +60ºC (-22ºF to +140ºF)
