CM106 Tripod
6.2 CM216 Mast Mounting Kit .2 CM216 Mast Mounting Kit
The CM216 attaches to the top of the mast, and provides a 3/4-in. or 1-in.
mounting pipe (1.05-in. or 1.32-in. OD) that extends 4 in. above the mast, as
shown in FIGURE 6-2. The CM216 attaches to the top of the mast, and provides a 3/4-in. or 1-in.
mounting pipe (1.05-in. or 1.32-in. OD) that extends 4 in. above the mast, as
shown in FIGURE 6-2.
FIGURE 6-2. CM216 Mast Mounting Kit
CM216
17
