11

4: 30 Then Do

7: Do (P86)
1: 10 Set Output Flag High (Flag 0)

8: Set Active Storage Area (P80)^3085
1: 1 Final Storage Area 1
2: 10 Array ID

9: Real Time (P77)^1712
1: 1220 Year,Day,Hour/Minute (midnight = 2400)

10: Sample (P70)^23951
1: 1 Reps
2: 1 Loc [ FaultStat ]

11: End (P95)

;

Check to see if there is Ice on the sensor and output it to final storage.

12: If (X<=>F) (P89)
1: 2 X Loc [ IceStat ]
2: 1 =
3: 0 F
4: 30 Then Do

13: Do (P86)
1: 10 Set Output Flag High (Flag 0)

14: Set Active Storage Area (P80)^10755
1: 1 Final Storage Area 1
2: 20 Array ID


15: Real Time (P77)^8112
1: 1220 Year,Day,Hour/Minute (midnight = 2400)

16: Sample (P70)^5446
1: 1 Reps
2: 2 Loc [ IceStat ]

;If there is ice on the unit, start a looping sequence that ends only when ice is no longer detected.

17: Timer (P26)
1: 0 Reset Timer
18: End (P95)
19: End (P95)

1

10.3

CR1000 Example – RS422 Outputs

The MD485 Multidrop Interface, the L15966 Wall Charger and the SC110
Interface Cable are required to measure the RS422 output on a CR1000 or
CR3000.

The MD485 Multidrop Interface must be configured for Active Ports |
RS232 and RS485, RS232 Baud Rate | 9600, and RS485 Baud Rate | 9600.
Refer to the MD485 Manual for configuration instructions.
