Thermal Management (cont’d)
Air Dam, 1 Side
42U x 800 -‐ 39386-‐X00
For 31.5” (800 mm) and 40” (1016 mm)
45U x 800 -‐ 39386-‐X03
wide cabinets
48U x 800 -‐ 39386-‐X06
52U x 800 -‐ 39386-‐X10
42U x 1016 -‐ 39384-‐X00
45U x 1016 -‐ 39384-‐X03
48U x 1016 -‐ 39384-‐X06
52U x 1016 -‐ 39384-‐X10
Air Dam, 2 Side
42U x 800 -‐ 39387-‐X00
For 31.5” (800 mm) and 40” (1016 mm)
45U x 800 -‐ 39387-‐X03
wide cabinets
48U x 800 -‐ 39387-‐X06
52U x 800 -‐ 39387-‐X10
42U x 1016 -‐ 39385-‐X00
45U x 1016 -‐ 39385-‐X03
48U x 1016 -‐ 39385-‐X06
52U x 1016 -‐ 39385-‐X10
X = Color (C=Black, E=Glacier White)
39386-XXX 39384-XXX
39387-XXX 39385-XXX
