Load cannot be
operated
+
info LED flashes
red
+
. green LED
flashes
load output is switched off
due to excessive battery
voltage
•
the load output automatically
switched on again as soon as
the battery voltage lies within
the permissible range
incorrect grounding
•
check the grounding
external charging source is
not voltage-limited
•
check the external charging
source
if necessary, switch off exter-
nal charging sources
Load cannot be
operated
+
info LED illumi-
nates green
defective load or installation
error
•
connect load correctly
replace load
Battery is not
charged
solar module not connected
•
connect the solar module
solar module connected with
incorrect polarity
•
connect the solar module
with the correct polarity
short circuit at solar module
input
•
correct the cause of the short
circuit
incorrect solar module
voltage
•
use a solar module of the
specified voltage
solar module defective
•
replace the solar module
Battery display
jumps quickly
large pulse current
•
tune the current consump-
tion to match the battery
capacity
battery is defective
•
replace the battery
8. Technical data
Solar charge controller
10 A
15 A
0 A
30 A
Max. module input short circuit
current at 50 °C
10 A
15 A
0 A
30 A
Max. load output current at 50 °C
10 A
15 A
0 A
30 A
Terminal size (fine/single wire)
16/5 mm² = 4/6 AWB
Weight
345 g
Dimensions l x w x h
187 x 96 x 45 mm
Enclosure protection class
IP 3
System voltage
1 V / 4 V
Ambient temperature allowed
–5 °C ... +50 °C
Max. voltage of Solar collector
47 V DC
Temperature compensation
–4 mV/K/Zelle
Charging voltage
State of charge SOC
1 V system 4 V system
Deep discharge warning
SOC < 40 %
11.7 V
3.4 V
Load switch-off
SOC < 30 %
11.1 V
3.4 V
Shift-in
SOC > 50 %
1.5 V
5.0 V
Boost charging (14.7 V)
SOC < 40 %
11.7 V
3.4 V
Equalisation charging (14.4 V)
SOC < 70 %
1.4 V
4.8 V
End-of-charge voltage (float)
SOC > 70 %
13.9 V
7.8 V
