Step 20: for connecting wires for, use M6 ring terminal (See fig 2, page 5) for the wire
size being used.
externaL fuSeS on tHe input anD output SiDeS:
please refer to Input / output Connection shown in figs 1 and 2.
the input and output connections should be made through 32V fast blow fuses (for
example, automotive fuses type Ato / AtC by bussmann / Littelfuse). the fuses should
be connected in series with the positive input and output wires. the fuse on the 12V
input side should be as close to the battery positive terminal as possible. this will
prevent the possibility of overheating / melting of the input side wires in case of short
circuit on the input side cabling (a battery can provide thousands of Amperes of current
during short circuit condition).
WarninG!
tHe Warranty WiLL be VoiDeD if tHe aboVe externaL fuSeS are not uSeD.
GrounDinG
6.3 mm / 0.25”, “Quick Disconnect”, Male Spade terminal is provided for grounding
(5, fig 1 for Step 7 and Step 10 and 5, fig 2 for Step 20). Use AWG #10 wire terminated
with 6.3mm / 0.25” - “Quick Connect” female mating terminal.
SeCtIOn 4 |
Installation
