Samlex America SK350 - Manual (Page 5)

4
2-1. Electrical Performance
Specification Model No.
Item SK120-112 SK120-124 SK120-148 SK120-212 SK120-224 SK120-248
Continuous Output Power 120W
Maximum Output Power 132W
Surge Rating (Max) 240W
Input voltage 12Vdc 24Vdc 48Vdc 12Vdc 24Vdc 48Vdc
Output Voltage 100 / 110 / 120Vac ± 5% 220 / 230 / 240Vac ± 3%
Frequency
(Switch Selections)
50 / 60Hz +/- 0.05%
Output Waveform Pure Sine Wave ( THD < 3% )
Efficiency (full load) Max *1 89% 91% 93% 92% 93% 94%
Input Voltage Regulation
10.5-15
VDC
21.0-30
VDC
42-60
VDC
10.5-15
VDC
21.0-30
VDC
42-60
VDC
Failure Indicator Red LED
Protection
Overload (Shut down),
Short Circuit (Shut down),
Reverse Polarity (Fuse),
Over / Under Input Voltage (Auto recovery),
Over Temperature (Auto recovery).
Remote Control Yes (ON / OFF mode controlled by hard wire) See 3-2
Safety Meet UL458 EN60950-1
EMC FCC Class A
EN55022:1997
EN61000-3-2:1998
EN61000-3-3:1995
EN55024:2001
e-mark
e13 023495
Operating Temperature Range 0 - 40 ℃
Storage Temperature Range -30℃ to 70℃
Cooling convection cooling
Dimensions 185(L)x147(W)x60(H)mm / 7.3(L)x5.8(W)x2.36(H) Inch
Weight 1kg
Note: The specifications are subject to change without notice.
*1 : This test condition is normal DC input (13.5V) and temperature 25℃.
