Connect the LED-Illuminated
Monorail to the Transformer
Remove the power feed cap from the power feed housing.
Completely back out the screw on the power feed cap.
POWER FEED
HOUSING
POWER FEED CAP
SCREW
LED-ILLUMINATED
MONORAIL
Place a Monorail section into the standoffs and power feed
housings.
Screw the power feed cap completely to the power feed
housing. Make sure that the power feed cap is not cross
threaded.
NOTE:
The standoffs should be installed to support the
Monorail while connecting Monorail to the surface mount
transformer. Refer to the instruction provided with the
standoffs.
POWER FEED CAP
Tighten the screw on the power feed cap for proper power
connection.
POWER FEED CAP
SCREW
POWER FEED HOUING
1A
2A
1A
2B
1
3
1
3
2
4
1A
2C
5
5
2
4
