2
Properly place the all the wires and wire nut connections
into the electrical box.
Mount the canopy to the electrical box with two #8-32
screws provided.
8 7
8 8
1C
#8-32
SCREW
2A
1
2
3
Connect the Monorail to the standoffs so that the Monorail is
secured in place. Refer to the instruction provided with the
standoff.
Make sure that the transformer power is off.
Place one power feed housing onto one Monorail section and
the other power feed housing on the other Monorail section.
For Dual Power Feed Canopies, make sure that the
Monorail sections are electrically isolated from each
other.
MONORAIL
POWER FEED
HOUSING
3
4
5
Completely back out the screw on the power feed caps.
Screw the power feed caps completely to the power feed
housings. Make sure that the power feed cap is not cross
threaded.
Tighten the screw on each power feed cap for proper power
connection.
POWER
FEED CAP
SCREW
2B
6
5
4 6
Connecting the Center Power Feed
Connector to the MonoRail
7400 Linder Ave, Skokie, IL 60077
800.323.3226 - 847.626.6300
www.lbllighting.com
© 2013 LBL Lighting.All rights reserved.The "LBL Lighting" graphic is a
registered trademark of LBL Lighting. LBL Lighting reserves the right to
change specifications for product improvements without notification.
A Generation Brands Company
SAVE THESE INSTRUCTIONS!
8
8
3/32 ALLEN
WRENCH
