LBL Lighting Fusion Jack Canopy 3 Light Rectangle Long LED - Manual

Installation Instructions for
Linear Multi-Port Canopy
G P I : ENERAL RODUCT NFORMATION
This product is suitable for dry locations only.
Product numbers ending in “-LED” can be dimmed with a low-
voltage electronic dimmer.All other models can be dimmed with a
standard incandescent dimmer.
IMPORTANT! If the canopy is wood, do not install any head
or pendant closer than 12 inches to this canopy. Heat from
the lamp may damage the wood.
Multi-Port Canopies
1
Lift the backplate out of the canopy.
BACKPLATE
Install the Backplate
Remove all the button head screws around the canopy.
Feed the power line wires through the hole in the
middle of the backplate.
Mount the backplate to the electrical box with the two
#8-32 screws provided.
BACKPLATE
980FSJ3PLCL
1.0
CK003RL-FJ_
1
2
CAUTION - RISK OF FIRE
This product must be installed in accordance with
the applicable installation code by a person familiar
with the construction and operation of the product
and the hazards involved.
Use minimum 90°c supply conductors.
