Install the Lamps & Shade
Push the lamp pins completely into the socket holes.
3
Reassemble the fixture by reversing figures 1A and 1B.
SOCKET
LAMP
For The Fixtures With Electronic Ballast,
Use
Watt Type Quad Tube G24q-1
MAX 13
Base 4-PIN Compact Fluorescent Lamp,
With Each Socket.
METAL SHADE
EXPOSED
THREADED NIPPLE
3B
3A
1
1
1
2
2
